Computer Troubleshooting - Mother Board

The motherboard is the large circuit board that every other computer component connects to, and it serves as the sole communications conduit between those devices. When the memory banks need some data from the hard drive, when a video game needs information from the video card, a key is pressed, the mouse is moved, or any other action is performed by any piece of hardware, the motherboard routes the output to the appropriate input. This universal role means that when something goes wrong with the computer, it could be a bad piece of connected hardware, or it could be a malfunctioning motherboard.

Problem: Nothing happens when I press the power button.

Solution: In rare cases, the power button itself breaks, so open the case and inspect the button for damage before trying anything else. If that isn’t the cause, then the motherboard may be fried due to electrical damage, but this problem most often happens after you install a hardware component and accidentally unseat the motherboard’s internal power plug from its socket. The size and shape of this socket (and sometimes there are two separate sockets) varies depending on the type and age of your motherboard, but the documentation that came with your computer should let you know where to look. You are looking for the power supply’s ATX (Advanced Technology Extended) plug, which has either 20 or 24 pins, and the ATX socket, which has an equal number of holes to accommodate the power pins. Some motherboards that have 20-pin ATX sockets also have a 4-pin ATX socket located elsewhere on the board, and both of these must be powered by separate cables for the motherboard to function. All you need to do is make sure the power plugs are fully seated in the sockets and the computer should boot.

Problem: When I press the power button, nothing appears on the monitor and the computer begins to beep.

Solution: Those beeps you hear are diagnostic codes that indicate the motherboard has detected some serious trouble. The beeping patterns and their meanings differ depending on the type of motherboard you have, so you’ll need to refer to the motherboard’s documentation or contact the manufacturer to find out the specifics.

Problem: When I press the power button, the computer seems to boot (the fans run properly, for example) but nothing appears on the monitor.

Solution: video rather than a separate video This indicates a problem with the video card, the monitor, or the motherboard’s integrated video or video expansion card slot. Check the cable between the video output and the monitor, make sure the monitor is turned on and set to the appropriate input, and reboot the computer. If there is still no video, open the case to make sure your add-in video card (if you have one) is seated properly and secured into place. If that’s not the problem, remove the video card according to the instructions it came with, connect the monitor to the motherboard’s integrated video output (if your motherboard has an integrated video output—not all do), making sure to enable the appropriate BIOS (Basic Input/Output System) setting as detailed in the computer’s manual, and see if that works. If your system uses the motherboard’s integrated card, install a video card in the motherboard’s video expansion slot and change the BIOS setting to bypass the integrated video hardware. If none of those options work, you may need to replace your system’s motherboard.

Problem: I just installed a new video card or sound card but the new one isn’t detected.

Solution: Many motherboards have integrated sound and video hardware, and the problem in this scenario is that the motherboard isn’t switching audio or video responsibilities over to the new hardware device. To force your motherboard to relinquish control to the new add-in card, you must disable the integrated audio or video hardware using the motherboard’s BIOS settings. This procedure differs from motherboard to motherboard so you’ll need to consult the computer’s manual.

Problem: I have to install a new hardware component or remove an old one, but the force needed to insert or remove it seems excessive, and I’m afraid I’ll crack the board.

Solution: No component should cause the motherboard to flex when it is inserted or removed, let alone cause enough force to threaten cracking the board. If this problem arises when inserting memory modules, check the edges of the memory slot to make sure any locking clips are completely opened. Most memory module clips are designed to lock into place automatically when the module is fully seated in the slot, but you may need to manually push each clip into its completely locked position. Another common problem when inserting memory modules is that some are designed to be pressed straight down into the slot while others are designed to be inserted at a slight angle and then swung into a vertical position, where they lock into place. Look at the instructions that came with the modules or the documentation that came with the motherboard to see which insertion method your memory slots require. When inserting expansion cards, particularly video cards, look for locking clips that must be opened before the card is inserted or held open as the card is inserted. Most modern motherboards have video card slots with locking mechanisms that must be manually held open when a card is removed, so look for one before accidentally applying excessive force when you remove the card. Never rock an expansion card or memory module back and forth to get it into place or you risk damaging the metal contacts, and never put pressure on the side of the card or the memory module or you’ll risk breaking off the delicate plastic slot. Don’t touch any metal contacts on the motherboard or the hardware, and be extremely careful when screwing or unscrewing expansion cards into place, because if the screwdriver slips it can scratch and ruin the motherboard.

Problem: I just installed a new hardware component that requires a power connection, and now the PC won’t boot or reboots itself at random times.

Solution: Inexpensive computers often come with very basic power supplies that can’t provide enough electricity to accommodate the fastest video cards, multiple hard drives, or other power-hungry components. Unfortunately the total wattage ratings most power supply manufacturers apply to their products overstate the amount of electricity they can consistently output, so even if you add up all of the wattage used by your components and it comes in under the stated output of the power supply, these types of problems can still happen. First you should remove the newly added hardware and see if the computer runs in its original configuration. If it does, you’ll likely need to upgrade to a new power supply or replace the new component with something that uses less wattage. Be sure to check carefully with the manufacturer before ordering a new power supply because some motherboards, like those found in a lot of Dell systems, use proprietary connections that prevent the installation of a third-party power supply.

Problem: I installed more memory but Windows doesn’t recognize it.

Solution: Bad memory modules aren’t very common, but test the computer with a different module if possible to see if the one you originally installed was a dud. The most common cause of this problem is that some motherboards require that memory modules be installed in pairs. Most RIMM memory modules, for example, must be installed in pairs that match exactly in speed and capacity or they won’t work. Newer systems that support dual-channel DDR SDRAM (Double Data Rate Synchronous Dynamic Random Access Memory) modules will work when the memory modules are installed singly, but performance is enhanced (sometimes dramatically) if you install matched pairs of RAM modules instead (i.e. you get better performance using two 512MB modules than from using a single 1GB module, even though the overall memory capacity remains the same). Check the manual carefully when installing memory to make sure you place the modules in the correct slots.

Problem: The computer never keeps track of time properly.

Solution: Motherboards have a CMOS (complementary metal-oxide semiconductor) memory area that is used to store the time, date, and essential data the PC used when starting up. The CMOS must be constantly powered to retain data, even when the PC is turned off or unplugged, so it is attached to a small battery. Open the case, find the small silver battery on the motherboard, and remove it carefully. Take it to a battery or electronics store to find an exact replacement, put the new one in, and access the BIOS or CMOS setup screen to make any necessary changes to the BIOS, as those settings are lost when the battery is removed. If you don’t see a silver battery, the motherboard may use a soldered- on battery, in which case you’ll need to have it professionally replaced or purchase a new motherboard.
